Green VDI F510

High performance cloud based thin client

GVDI F510 is a cost-effective and compact thin client based on AMD LX platform with high speed, low power consumption and 4K output supported, F510 can meet the demands of various virtual desktop accessing scenarios making it most powerful and economical thin client.

About this item:

High reliability
High speed and low power consumption processor with fan-less and no-moving parts design, highly improving reliability.

Support 4K output and dual display.

Multiple VDI protocol supported
Widely supports Citrix ICA/HDX, VMware PCoIP and Microsoft RDP.

Environment friendly
Low CO2 emission, low heat emission, noise-free and space saving.


Cloud computing made easy with Green VDI F510


Do it all with total security. The era of complex, non-secure PC solutions is almost over. Green VDI cloud enabled virtual desktop solution, on the other hand, enables all computing resources and data to be transferred to a centralized server in a secure data center and lowers support overheads for the enterprise. This enhances enterprise data management and security while delivering an immaculate, uncompromised end user experience over standard IP networks.

PCoIP zero client makes it possible to deliver workstation class performance for professional applications including 3D Graphics solution, Digital Content Creation, video editing and advanced knowledge worker level business software.


Highly versatile

This book-size desktop device can be utilized with cloud computing solutions like Vmware™ Horizon View™ Client, Citrix receiver and supports Microsoft Remote Desktop Client. It supports up to six USB, a Speaker, a Microphone, a Headphone and Ethernet connector



High Resolution Output

Supports display output at 1920x1080 resolution and the highest pixel processing power.

With cloud enabled technology, your enterprise applications can be located and managed in the cloud or in your data center while your users continue to enjoy premium interactive experience with their desktops and applications.



Small size

Offers industry-leading low power consumption design and engineering technology. The net result is a small, quiet, low power and reliable device that requires minimal IT administration and support.


High Stability

Fanless & fully integrated design



Product Specification


Processor AMD GX218GL Dual-Core 1.8GHz
Available Operating System WES7 / WIN 10 IOT / TOS
VDI/HSD Support Citrix Receiver / VMware view / Microsoft RDP 8 Compatible
Management CDMS2
RAM (DDR3L) 2GB
Storage SSD) 8GB
Display DVI-I x 1
Resolution 1920x1200@60Hz
Color Depth 32 bits
Dual Display Support
LANx 1 (10/100/1000 Base T Fast Ethernet, RJ-45
USB ports x 1 (USB 3.0 front), x 5 (USB 2.0 rear)
Audio PortLine out x 1 , Mic in x 1, (1/8-inch mini jack)
Dimension131mm x 31.5mm x 167mm(stand not included)
131mm 131mm x 76mm x 178mm(stand included)
Net Weight0.5kg
AdapterWorldwide auto-sensing 100-240V AC, 50/60 Hz, 12V/3A DC
Power Consumption<15W
Stand Vertical feet standard
Security Standard-Kensington anti-theft keyhole
Operation Temperature00C to 400C
Relative Humidity30% to 90% non-condensing
OPTIONAL
RAM (DDR3L)Available at 8 GB
Storage (SSD)Available at 128GB
Network1 x Mini-PCIE wireless module (one USB port will be used for internal Wifi)
DP3840 x 2160@60Hz
MountingVESA mounting kit
USB 2.0x 4 rear

1: TOS: terminal operating system (Linux)

2. CDMS: Centerm desktop management system
